When working near overhead power lines, choosing the right hydraulic components is an important part of equipment safety. For electrical utilities, tree service providers, and other professionals operating aerial equipment, hydraulic hoses must meet the demands of the application while addressing potential electrical hazards.

The Parker 518D Non-Conductive Thermoplastic Hydraulic Hose is designed for hydraulic systems where electrical non-conductivity is essential. Its specialized construction makes it a solution for bucket trucks, aerial lifts, and other applications where conductive hydraulic hose is unsuitable.

Designed for Applications Where Electrical Safety Matters

Bucket trucks and aerial lifts allow workers to reach elevated work areas, including locations near energized power lines. In these environments, selecting hydraulic components designed for the application is a critical consideration.

Parker's 518D hose is engineered for hydraulic circuits requiring electrical non-conductivity. Its design helps prevent the hose itself from becoming a conductive path, making it particularly relevant for equipment used by electrical utility crews and tree care professionals.

Common applications include:

• Electrical utility equipment used for overhead line work
• Tree service bucket trucks operating near power lines
• Aerial lifts and mobile hydraulic equipment
• Other hydraulic systems requiring non-conductive hose

Non-conductive hose is one component of an overall safety system. It does not make a bucket truck, aerial lift, or operator safe from contact with energized power lines. Equipment insulation, inspection, safe work practices, and applicable electrical safety requirements remain essential.

Explore the Parker 518D



Recognizable Design for Demanding Environments

The 518D's bright orange cover provides a distinctive visual identifier for non-conductive hose. Its polyurethane construction also helps resist abrasion, supporting use in demanding mobile equipment environments.

Additional features include:

Resistance to fluid permeation: The nylon inner tube provides resistance to permeable fluids in most sizes. The -16 size uses a copolyester tube.

Flexible hose routing: Thermoplastic construction can help accommodate equipment layouts where routing space is limited.

Twin-line and multi-line options: Available bonded configurations can help organize hydraulic lines and support installation requirements.

Abrasion-resistant cover: The polyurethane jacket helps protect the hose against wear associated with equipment use.

For -4 construction, Parker specifies a compact, high-density reinforcement braid and a heavier polyurethane cover to improve abrasion resistance and separation between bonded twin-line or multi-line assemblies.

Parker 518D: Key Specifications

The 518D meets SAE J517 100R7 requirements and is available across a range of hose sizes. Because pressure ratings and certain operating limits vary by size, always consult Parker's current technical documentation before selecting a hose for a specific system.

Key specifications to consider include:

• Hose type: Non-conductive thermoplastic hydraulic hose
• Nominal inside diameter: 1/8 inch to 1 inch
• Temperature range: -40°F to 212°F, subject to size and fluid limitations
• Maximum temperature for specified water-based and synthetic fluids: 135°F (57°C)
• Cover material: Polyurethane
• Reinforcement: Synthetic fiber braid
• Cover color: Orange
• Vacuum rating: Up to 28 inHg, subject to Parker's application specifications

The correct hose size, working pressure, fluid, temperature, and fitting combination should be verified for every application.

Fitting Compatibility and Assembly

Selecting the right hose is only part of building a reliable hydraulic assembly. Proper fitting selection and assembly procedures are equally important.

Parker's 518D can be coupled with its 56 Series hose fittings. Certain sizes are also approved for 51R Series field-attachable and rapid-assembly connections. Compatibility depends on the specific hose size and fitting configuration.

The hose can be assembled using compatible Parker crimping equipment and the appropriate crimp specifications. Before assembly, consult Parker's current documentation to confirm the approved fitting, die, crimp setting, and assembly procedure.

Following the manufacturer's recommendations helps ensure the finished assembly is appropriate for the intended operating conditions.

Find the Right Hydraulic Hose for Your Application

When hydraulic equipment operates near electrical hazards, hose selection requires careful consideration of both hydraulic performance and electrical safety requirements. Parker's 518D provides a purpose-designed non-conductive option for aerial equipment and other applications where conductive hose is unsuitable.

Triad Technologies partners with Parker Hannifin to help customers identify hydraulic hose and fitting solutions for their equipment. Whether you're specifying a new hose assembly or evaluating components for existing equipment, Triad can help you explore the available options.

Contact Triad Technologies to discuss your application and find the right Parker hydraulic hose solution for your needs.

An oversized cylinder can increase compressed air consumption and equipment costs without improving performance. An undersized cylinder may struggle to move the load consistently. Proper sizing helps you find the right balance between force, speed, and efficiency.

4 Factors to Consider When Sizing a Pneumatic Cylinder

Cylinder sizing starts with understanding the application's requirements. Four key factors help narrow down the right option.

Factor	What to Consider
Bore Diameter	Determines piston area and contributes to the force the cylinder can generate.
Operating Pressure	Affects the force available at the cylinder. Use actual operating pressure, not just the compressor's rated pressure.
Stroke Length	Determines how far the piston rod must travel to complete the movement.
Speed and Cycle Rate	Help determine the airflow and control requirements.



How Much Force Does Your Cylinder Need?

Cylinder force depends on piston area and operating pressure. For a typical single-rod cylinder's extension stroke, use this formula to calculate theoretical force:

Force = Pressure × Piston Area

Piston area is calculated using the bore diameter. For pressure in psi and bore diameter in inches, the resulting force is measured in pounds-force (lbf).

Example: A cylinder with a 2-inch bore operating at 80 psi produces approximately 251 lbf of theoretical extension force.

Actual usable force will be lower due to friction and other losses. Retraction force is also lower because the piston rod reduces the effective piston area.

The cylinder should provide sufficient force for the application without adding unnecessary capacity. Account for the load, friction, and expected operating conditions when determining the required force.

Choosing the Right Parker Pneumatic Cylinder

Parker offers pneumatic cylinder options for a range of mounting standards, space constraints, and load requirements.

Parker Cylinder Option	Application Considerations
P1F Series	ISO 15552 cylinder applications
4MA Series	Applications designed around NFPA cylinder dimensions
Compact Cylinders	Installations with limited available space
Guided Cylinders	Applications requiring additional load guidance or support against side loads



The best option depends on the required force, stroke, mounting arrangement, and operating conditions. Always verify the specifications of the selected cylinder series before finalizing your choice.

When a Bigger Cylinder Isn't Better

An oversized cylinder may still complete its stroke while consuming more air than necessary or making motion difficult to control. However, poor performance is not always a sizing issue.

Restricted airflow, pressure losses, incorrect mounting, and mechanical misalignment can also affect performance. Increasing cylinder size without identifying the root cause may add cost and air consumption without solving the problem. Review the actual load, operating pressure, stroke, and cycle requirements before replacing a cylinder. The goal is to select a cylinder that meets the application's needs, not simply the largest option available.

Find the Right Pneumatic Cylinder with Triad

As a premier Parker Hannifin distributor, we help customers identify the right pneumatic solution for their applications. Whether you're sizing a new cylinder or troubleshooting an existing system, our team can help you evaluate your requirements and determine which options are worth considering.

Contact us for help selecting the right pneumatic cylinder for your application.

With several configurations available, it can be difficult to know where to start. That’s why SICK offers different versions of its nanoScan3 and microScan3 safety laser scanners. The right choice comes down to a few key questions: How does the scanner need to integrate with your control system? How many monitoring cases does your application require? And what protective field range do you need?

Use those three considerations to narrow down the right scanner for your application.

Step 1: How Does the Scanner Need to Integrate?

The first step is determining how the safety laser scanner will communicate with the rest of your machine or safety system.

The nanoScan3 and microScan3 can be configured for several integration options, including:

• I/O
• EtherNet/IP™ CIP Safety™ or EFI-pro
• PROFINET PROFIsafe or EtherCAT FSoE

Your existing control architecture can help determine which scanner configuration makes the most sense.

For applications using standard I/O, the decision process moves to the number of monitoring cases required. For applications using a safety network, the scanner’s network compatibility becomes an important part of the selection.

SICK offers network-integrated versions of the microScan3 that support protocols such as PROFINET PROFIsafe and EtherNet/IP CIP Safety, allowing safety-related communication to be integrated into the machine’s control architecture.

Step 2: How Many Monitoring Cases Do You Need?

Once you've determined how the scanner will integrate with your system, consider how many monitoring cases your application requires.

Monitoring cases allow the scanner to use different configurations for different operating conditions. For applications with simpler requirements, a Core model may provide the functionality needed. If your application requires multiple configurations or greater flexibility, a Pro model can accommodate up to 128 configurable fields and monitoring cases.

This gives you the first major distinction between the product options:

• Core: Up to 2 monitoring cases
• Pro: Up to 128 monitoring cases

But there's one more important factor to consider before selecting a scanner: how far does your protective field need to extend?

Step 3: How Much Protective Field Range Do You Need?

Now consider the size of the area you need to protect. This is where the choice between the nanoScan3 and microScan3 becomes straightforward:

Need a protective field up to 3 meters?
Look to the nanoScan3 family.

Need a protective field greater than 3 meters?
The microScan3 family provides the extended range needed, with a protective field of up to 9 meters.

From there, your monitoring-case requirements help determine whether the Core or Pro version is the better fit.

Putting the Pieces Together

With your integration, monitoring-case requirements, and protective field range identified, you can narrow your selection to one of four primary options:

Application Needs	Scanner to Consider
Up to 3 m + simpler monitoring requirements	nanoScan3 Core
Up to 3 m + greater monitoring flexibility	nanoScan3 Pro
More than 3 m + simpler monitoring requirements	microScan3 Core
More than 3 m + greater monitoring flexibility	microScan3 Pro



nanoScan3 Core: Compact and Straightforward

Choose the nanoScan3 Core when your application needs a compact safety laser scanner with a protective field range of up to 3 meters and a more straightforward monitoring configuration. Its small form factor can be especially beneficial when installation space is limited.

nanoScan3 Pro: Compact With More Flexibility

The nanoScan3 Pro is a good fit when you still need the compact size and 3-meter protective field range of the nanoScan3, but your application requires more monitoring cases and configurable fields. With up to 128 monitoring cases, the Pro version provides significantly more flexibility for changing machine or vehicle conditions.

microScan3 Core: More Coverage

When your application requires a protective field beyond 3 meters, the microScan3 Core provides the additional coverage needed, with a protective field range of up to 9 meters. It is designed for applications where extended protection is more important than having the extensive monitoring flexibility of the Pro version.

microScan3 Pro: Maximum Flexibility

For applications that need both extended range and a high degree of configurability, the microScan3 Pro offers up to 9 meters of protective field range and up to 128 monitoring cases.

Its ability to support multiple protective fields and detailed configuration makes it a strong option for more complex applications, including robotics and mobile applications where operating conditions can change.

Choosing the Right Safety Laser Scanner Doesn't Have to Be Complicated

There isn't one safety laser scanner that is right for every application. The best choice depends on how the scanner needs to integrate, how many monitoring cases your application requires, and how much area needs to be protected.

Starting with those three questions can help narrow the options quickly:

1. How does it need to integrate?
I/O, EtherNet/IP CIP Safety or EFI-pro, PROFINET PROFIsafe, or EtherCAT FSoE?

2. How many monitoring cases are required?
A smaller number of cases or the flexibility of up to 128?

3. How much protective field range do you need?
Up to 3 meters or more than 3 meters?

Once those requirements are clear, the choice between the nanoScan3 Core, nanoScan3 Pro, microScan3 Core, and microScan3 Pro becomes much easier.

Still unsure which configuration fits your application? Triad Technologies can help you evaluate your safety requirements and find the SICK safety laser scanner that fits your system.

Enerpac Armor Stack™ Modular Storage Cases take a different approach. Designed as a modular storage platform built around Enerpac tools, Armor Stack combines heavy-duty protection with stackable, interlocking cases that can be configured for specific applications. The result is a storage and transport system designed to help keep hydraulic tools organized, protected, and ready for deployment in demanding industrial environments.

Built Around a Modular Storage System

The Armor Stack system is designed to do more than hold tools. Multiple cases can stack and lock together as a single integrated system, allowing users to build configurations around the tools and equipment required for a particular job. This modular design can help simplify tool deployment while reducing the number of individual cases that need to be transported to the work area.

Designed for Demanding Industrial Environments

Industrial tools can encounter rough handling, vibration, changing temperatures, dust, water, and other challenging conditions during transportation and use. Armor Stack cases are designed with these conditions in mind. The system has been validated against MIL-STD-810H, ATA300, DEF-STAN, and IP67 performance requirements, addressing conditions including impact, vibration, water intrusion, dust exposure, temperature changes, and transport durability. That protection is built into several aspects of the case design.

IP67 Protection

IP67-rated sealing helps protect the contents from dust ingress and water immersion, providing protection when cases are exposed to demanding environments.

ATA300-Compliant Breather Port

The integrated breather port equalizes internal and external air pressure, helping prevent vacuum locks during transportation and supporting acceptance for airline transport.

Metal-to-Metal Latching

Armor Stack cases use a metal-to-metal latching system to provide secure, stable stacking. The interlocking design helps keep cases together during transportation and deployment.

Secure Tool Storage

Selected kits feature pre-cut foam interiors matched to Enerpac tools. The foam helps hold tools securely in place and minimizes movement during transit.

Designed for Easier Transport

Protection is only part of the equation. Industrial tools also need to get from storage to the work area efficiently. Armor Stack cases include features designed to simplify handling and transportation. Large ergonomic overmold handles provide a more comfortable grip, while the optional ARMRT2 Mobility Transport Kit adds wheels to improve maneuverability across smooth surfaces.

Additional features help secure cases during transport, including:

• Padlockable locations for added security
• Ratchet strap locators to help position straps
• Zip-tie holes near the front latches
• An accessory socket for the compact wheel attachment and future accessories

Together, these features give users multiple ways to move, secure, and organize their equipment based on the application.

Storage That Can Be Configured Around the Job

One of the key advantages of the Armor Stack platform is its ability to accommodate different tool configurations.

The ARMRC8 is available as an empty modular case for users who want to store their existing tools. Divider-ready slots provide flexibility for separating tools and equipment when foam isn't being used, including non-Enerpac tools.

For users looking for a ready-to-deploy solution, Enerpac also offers preconfigured Armor Stack kits built around specific hydraulic applications.

Current Armor Stack Configurations

Kit	Description	Maximum Operating Pressure
ARMRPK142	Lightweight portable hand pump kit	10,000 psi
ARMRPK392	High-performance hand pump kit	10,000 psi
ARMRPK39	Durable steel hand pump kit	10,000 psi
ARMRTK10	10-ton hydraulic lifting kit	10,000 psi
ARMRTS10HTB	10-ton hydraulic cylinder and hand pump set	10,000 psi



For a more comprehensive hydraulic solution, the ARMRTS10HTB combines the Armor Stack storage system with a two-speed P392 hand pump and a range of 10-ton hydraulic cylinders and accessories. The set includes two ARMRC8 Armor Stack cases, a 45-degree angled gauge adaptor assembly, a 6-foot high-pressure hydraulic hose, the ARMRT2 Mobility Transport Kit, a JBI10 base plate, and multiple cylinder options for general-purpose lifting, low-height applications, spreading, and hollow-plunger applications.

The available kits range from approximately 33 to 62 pounds, depending on configuration, while the ARMRC8 case itself weighs 20.3 pounds.

ARMRC8 Technical Specifications

For applications where case dimensions and handling requirements are important, the ARMRC8 provides a compact footprint while still offering space for hydraulic equipment.

Specification	ARMRC8
Exterior dimensions	30.5 x 9.0 x 17.1 in.
Interior dimensions	27.1 x 7.5 x 14.5 in.
Case weight	20.3 lb
Stacked case capacity	Up to 500 lb
Protection	IP67-rated
Locking	Padlockable
Mobility	Compact wheel kit available
Validation	MIL-STD-810H, ATA300, DEF-STAN



Stacked cases can support up to 500 pounds, giving users the ability to build larger configurations without sacrificing the modular nature of the system.

More Than a Tool Case

Armor Stack is designed around a simple idea: hydraulic tools should be protected and organized in a way that makes them easier to transport and deploy.

Instead of relying on individual storage cases for every tool or kit, the modular Armor Stack platform allows users to build configurations around the requirements of the job. Stackable cases, integrated latching, protective sealing, mobility options, and application-specific kits bring storage and transportation together in one system.

Get the Right Storage Solution for Your Hydraulic Tools

From individual tool storage to application-specific hydraulic kits, Armor Stack provides a modular approach to protecting, organizing, and transporting hydraulic equipment.

Contact Triad Technologies to learn more about Enerpac Armor Stack Modular Storage Cases and find the right configuration for your application.

Since its founding in 1976, FCA has supplied aviation filtration systems, filter vessels, quality control testing equipment, petroleum handling equipment, pipeline supplies, loading arms, pressure control valves, and refueling nozzles to operations ranging from county airports to major international airports. The combination of Triad and FCA creates a deeper filtration and fluid handling offering for the aviation and fuel markets,  and FCA’s existing team will continue to provide best-in-class service to its customers.

“We are pleased to welcome the FCA team to the Triad family,” stated Greg Wissman, President and Chief Executive Officer of Triad. “Filtration is an area we have been deliberate about expanding, and FCA gives us both the product breadth and the technical depth to do it well. FCA has spent nearly five decades earning the trust of the aviation fueling community, and pairing that reputation with Triad’s distribution platform allows us to deliver a wider range of filtration and fluid handling solutions than either company could provide on its own. We are incredibly excited to add multiple Parker Hannifin-owned brands to our existing portfolio of products, most notably Velcon and Meggitt. Further, I expect Triad to continue to expand its filtration business in the coming years through additional investments and acquisitions.”

Gordon Tompkinson and Brian Tompkinson, co-owners of FCA, added, “Our father founded this business in 1976, and since then our customers have counted on us to know their operations, keep the right parts on the shelf, and get them what they need when they need it. Joining Triad gives those customers access to a significantly broader set of products and technical resources while keeping the same level of service they have relied on for many years.”

“FCA meaningfully enhances Triad’s filtration offering and establishes an attractive position in aviation and the fuel filtration markets,” stated Charlie Denison, Managing Director at Shorehill Capital. “We are thrilled to welcome FCA and the Tompkinsons into the Triad family.” Triad and Shorehill Capital partnered in October 2019. Since that time, Triad has substantially expanded its product breadth to include seals, O-rings, and filtration solutions.

Visit our website for more information.

Thank you to everyone who stopped by the Triad Technologies tent during the 2026 Farm Science Review in London, Ohio! Held September 22–24 at the Molly Caren Agricultural Center, this year's event brought together people from across the agricultural industry for three days of equipment, technology, education, and networking.

One of the highlights was seeing so many young people exploring the future of agriculture at this year's show. More than 1,000 high school students attended the Farm Science Review to learn more about farming, agricultural technology, and potential careers in the industry. With many FFA students among those attending, the event gave the next generation of agricultural professionals a chance to learn, ask questions, and experience the industry firsthand.

For those who couldn't make it to this year's show, here’s a recap of some of the products and solutions we had on display:

Hoses & Fittings
We featured a variety of products for hydraulic hose and fluid handling applications, including Parker’s 387TC hydraulic hose.

Lubricants & Maintenance
Proper maintenance is essential for keeping agricultural equipment running smoothly, so we featured several products designed to make routine maintenance easier. Our display included 5-gallon Lucas Oil buckets, Parker oil filtration carts, Parker oil analysis kits, and LockNLube products.

We also highlighted LockNLube's BTX Battery Transfer Pump, which quickly became one of the biggest attractions inside the tent. The battery-powered pump provides a convenient way to transfer fluids and simplify routine maintenance tasks.

Facility Organization
Keeping equipment, hoses, and work areas organized can make maintenance easier and help keep the shop running efficiently. On display were Reelcraft hose reels, providing a simple way to keep hoses off the ground, organized, and out of the way.

Crimpers
If your operation regularly needs hydraulic hoses, having a crimper on-site can be a real time-saver. Our display gave attendees a look at a complete hose crimping setup, along with an example of the equipment and inventory needed to get started. It was a simple way to see what an in-house crimping operation could look like and what it might take to put one in place.

Cleaning & Industrial Solutions
We also showcased Spill Tackle and Blue Monster products for cleaning, maintenance, and spill response. The display gave visitors a look at some of the products available through Triad for everyday shop and equipment needs.

Giveaways

Visitors to the Triad Technologies tent also had the opportunity to enter giveaways for a Reelcraft reel or four tickets to the Bengals vs. Colts game at Lucas Oil Stadium in Indianapolis. Congratulations to our winners:

• Reelcraft Reel: Gary L.
• Bengals vs. Colts Tickets: Brandon M.

Thank You for Visiting Triad at Farm Science Review

We want to thank everyone who visited the Triad Technologies tent during the 2026 Farm Science Review. It was great to connect with customers, industry professionals, and the many students who are beginning to explore their future in agriculture.

Events like Farm Science Review give us an opportunity to connect with the agricultural community, learn more about the challenges our customers face, and share products and ideas that can help make their jobs a little easier.

We look forward to seeing you at Farm Science Review again next year! If you want to learn more or continue a conversation from the show, contact Triad Technologies.

When it comes to sealing performance, selecting the right seal material can be just as important as selecting the right seal design. Pressure, temperature, chemical exposure, friction, wear, and movement can all affect how a seal performs in an application.

PTFE is a popular material for demanding sealing applications because of its low friction, chemical resistance, and broad temperature capabilities. However, not all PTFE seals are made from the same compound. Different fillers can be added to PTFE to improve specific performance characteristics. Virgin PTFE, glass-filled PTFE, carbon-filled PTFE, and bronze-filled PTFE each offer different advantages depending on the application.

Spring Energized Seals, are a popular choice for many seal scenarios and understanding these material differences can help you create a seal designed to perform under the conditions your application demands.

What Is a Spring Energized Seal?

A Spring Energized Seal combines a PTFE sealing element with a metal spring or energizer. The spring applies continuous force to the sealing lip, helping maintain contact with the mating surface as operating conditions change.

The PTFE jacket provides the primary sealing properties, while the spring helps maintain sealing force. This combination makes Spring Energized Seals well suited for applications where chemical resistance, low friction, temperature performance, or challenging operating conditions are important. Because the PTFE jacket is such an important part of the seal, selecting the right PTFE blend is a key consideration.

What Is a PTFE Blend?

PTFE, or polytetrafluoroethylene, is a thermoplastic material commonly used in sealing applications where chemical resistance, low friction, and temperature performance are important. Virgin PTFE provides many of these properties naturally. However, unfilled PTFE can have limitations in applications involving high loads, deformation, or significant wear.

To address these limitations, manufacturers add fillers to the PTFE material. These fillers can change the  mechanical, thermal, and wear characteristics, allowing the material to better match specific operating conditions. The right blend ultimately depends on what the Spring Energized Seal needs to withstand.

Explore Your PTFE Compound Options

There is no single PTFE blend that is best for every application. Each material offers different performance characteristics based on factors such as load, movement, wear, chemical exposure, and dimensional stability.

Select a material below to learn more about its characteristics and when it may be the right choice for your application.





How Do You Choose the Right PTFE Blend?

Selecting a PTFE blend starts with understanding the conditions the seal will encounter during operation. The material that works well in one application may not be the best choice for another.

Pressure: How much pressure will the seal experience?

Higher-pressure applications may require a blend with improved resistance to deformation and extrusion. Filled PTFE materials can provide greater mechanical stability than virgin PTFE in demanding conditions.

Temperature: What temperatures will the seal experience?

Both the operating temperature and potential temperature spikes should be considered. The selected blend must maintain its performance throughout the application's temperature range.

Chemical Compatibility: What media will the seal contact?

PTFE is known for its excellent chemical resistance, but the addition of fillers can affect the overall chemical compatibility of the blend. The process media should be evaluated before selecting a filled PTFE material.

Movement: Is the seal static, reciprocating, or rotating?

A seal exposed to continuous or repeated movement may require greater wear resistance than a primarily static application. Dynamic applications can benefit from PTFE blends designed to improve wear and friction performance.

Friction and Wear: How much friction will the application generate?

Applications involving continuous movement can place additional demands on the sealing material. Selecting a blend with appropriate wear and friction characteristics can help improve seal life and overall equipment performance.

Mating Surface: What material and surface finish will the seal run against?

The sealing material and mating surface work together. Certain fillers may be more abrasive against softer materials, making surface compatibility an important part of the selection process. Controlling the surface finish is generally required for optimal seal performance.

The Right PTFE Blend Starts With the Application

Choosing a PTFE blend isn't simply about selecting the strongest or most wear-resistant material. The best compound is the one that matches the conditions of the application.

Virgin PTFE may be the right choice when chemical resistance and low friction are the priority. Glass-filled PTFE can provide improved dimensional stability and mechanical performance. Carbon-filled PTFE can offer advantages in demanding dynamic applications, while bronze-filled PTFE can provide increased strength and load-bearing capability. With multiple factors influencing seal performance and hundreds of filler materials and combinations available, material selection can become complicated quickly.

That's where working with a sealing specialist can make a difference.

Find the Right Sealing Solution With Triad Technologies

At Triad Technologies, we understand that sealing requirements vary from application to application. Our team offers a range of sealing solutions in different styles, sizes, and materials, along with engineering expertise to help customers develop solutions around their specific application requirements.

Whether you're dealing with pressure, temperature, harsh chemicals, dynamic movement, or demanding wear conditions, selecting the right material is an important step toward improving seal performance and reliability.

Need help selecting the right PTFE seal for your application? Contact Triad Technologies to work with a sealing specialist.

The SICK sensingCam SEC200 combines the simplicity of a sensor with industrial vision technology to deliver dependable 1D and 2D code reading in a cost-effective package. By making it practical to deploy identification at more points throughout a process, the sensingCam SEC200 helps operations collect more data, improve traceability, and gain deeper insight into product movement.

Reliable Code Reading for Your Operation

The sensingCam SEC200 delivers dependable 1D and 2D code reading for both stationary and moving objects. Its wide depth of field and stable decoding performance help accommodate variations in product position, reducing setup effort and the need for precise presentation.



Application	How the SEC200 Can Help
Manufacturing & Production	Identify components, wafer carriers, paper products, and sheet metal coils for improved traceability.
Manual Workstations	Enable hands-free code reading for order verification and assembly traceability.
In-Line Verification	Verify packaging and components while products move through production.
Logistics	Identify parcels, cartons, pallets, and conveyed materials throughout the supply chain.



This flexibility makes the sensingCam SEC200 well suited for applications where parts, packages, or materials may not always arrive in exactly the same location. More importantly its attractive price-to-performance ratio makes it practical to add barcode reading at additional process stages, providing greater operational visibility beyond traditional start-and-end checkpoints.

A Solution for Multiple Applications

From manual workstations to conveyor-based production and logistics operations, the sesningCam SEC200 can support a wide range of identification tasks using a common platform. This allows organizations to standardize barcode reading across multiple applications while simplifying deployment and training.

Simplified Setup and Operation

Deploying code-reading technology shouldn’t require extensive software installation or specialized training. The sensingCam SEC200 uses browser-based configuration allowing users to commission and adjust the device directly through a standard web interface via USB-C without any specialty software.

Settings can easily be replicated across multiple devices to streamline larger deployments, while visual an acoustic feedback provide immediate scan confirmation during operation. This result is a code-reading solution that combines modern image-based technology with a user experience familiar with sensor users.

Hands-Free Code Reading at Manual Workstations

Manual workstations can benefit from the SEC200's ability to automatically detect and read codes as an operator presents a part or product.

Because no manual trigger is required, operators can keep their focus on the task at hand while the SEC200 handles identification. LED and audio feedback can provide confirmation, while consistent performance helps accommodate variations in how parts are positioned. This can support applications such as:

• Order verification
• Assembly traceability
• Hands-free barcode scanning
• Manual picking stations

By eliminating the need for manual triggering, the sensingCam SEC200 helps streamline operator workflows while maintaining reliable identification. The result is a more efficient workstation where traceability can be captured without adding extra steps to the process.

Keep Code Verification Moving

The sensinCam SEC200 isn’t limited to station applications. It can capture and verify codes on moving production lines while maintaining throughput.

Stable decoding across variations in object height and position helps support conveyor applications, such as packaging inspection, component verification, ad product tracking. By maintaining accurate identification without slowing production, the sensingCam SEC200 helps preserve product flow while capturing the data needed for quality and operational visibility.

Built for Industrial Environments

Industrial code-reading equipment needs to perform reliably in the environments where manufacturing and logistics take place every day. The sensingCam SEC200 features an industrial-grade housing, IP65 protection, and EMC shielding. It’s designed to provide dependable performance in environments where dust, vibration, ad changing temperatures can be part of everyday operation. The industrial design makes the sensingCam SEC200 a fit for applications that require reliable identification day after day.

A Simpler Approach to Identification

Barcode data is a foundational building block for traceability, process control, and operational visibility. The challenge isn’t simply reading codes. It’s collecting meaningful data across the entire operation without introducing unnecessary cost or complexity.

The SICK sensingCam SEC200 provides a cost-effective way to expand identification throughout manufacturing, assembly, packaging, and logistics processes. With dependable 1D and 2D code reading, straightforward deployment, and industrial-grade durability, it helps organizations capture data at more touchpoints and gain a clearer understanding of how products move through their operation.

See how the sensingCam SEC200 can work for you. Request a demo or contact us to learn more.

The good news? Improving compressed-air efficiency does not always require a complete system overhaul. Often, it starts by identifying where air is being used unnecessarily.

Here are five common areas to look at.

1. Running More Pressure Than the Application Needs

More pressure is not always better. Many facilities maintain a high system pressure because one machine or process requires it. The result is that other pneumatic devices may be operating at a higher pressure than necessary.

That can lead to increased air consumption, additional component wear, and more leakage throughout the system. That extra pressure comes at a cost.

A better approach is to determine the pressure actually required at the point of use and regulate individual applications accordingly.

Parker air-preparation products, including the Global FRL family of filters, regulators, filter/regulators, and related components, can help control pressure locally while maintaining consistent air preparation at the machine.

Instead of asking how much pressure is available, ask: How much pressure does the application actually need?

Regulating pressure at the point of use can help ensure each application receives the pressure required for reliable performance, without using more compressed air than necessary.

2. Ignoring Compressed-Air Leaks

Leaks are one of the most common sources of wasted compressed air.

A small leak from a fitting, tube connection, hose, valve, or cylinder seal may not seem significant by itself. Multiply that leak across dozens or hundreds of components operating around the clock, and the cost can become substantial.

Common leak points include:

• Push-to-connect fittings
• Damaged tubing
• Hose assemblies
• Valve and cylinder seals
• Threaded connections
• Regulators
• Quick disconnects

Leaks also force the compressor system to work harder to maintain plant pressure. Regular leak detection and maintenance can help identify these issues before they become a larger source of wasted energy. Using reliable fittings, tubing, valves, and pneumatic components can also help reduce potential leak points throughout the system.

When leaking connections or aging tubing are identified, Parker Prestolok push-to-connect fittings and pneumatic tubing provide options for repairing or upgrading those connection points. The important thing is not simply replacing a leaking fitting with another fitting. The entire connection should be evaluated, including tubing condition, tube preparation, thread condition, routing, and component wear.

3. Using Continuous Air for Blow-Off Applications

Blow-off applications are everywhere in manufacturing.

Compressed air may be used to:

• Clear chips or scrap
• Clean parts
• Dry surfaces
• Move lightweight material
• Cool components
• Clear tooling
• Remove debris from stamping dies

The issue is that many of these applications use continuous open airflow even though the process may only need a short burst of air. If an open nozzle blows for several seconds during every machine cycle, compressed-air consumption can add up quickly.

One way to address this is to convert continuous airflow into pulsed air. The Parker Air Saver Unit is designed specifically for this type of application. The Air Saver converts a continuous air blow into a series of ON/OFF pulses. During the OFF portion of the cycle, compressed air is not being consumed.

Parker states that the technology can reduce air consumption by up to 50% in appropriate blow-off applications.

What Could This Be Worth?

Parker’s Air Saver literature includes a sample application based on:

• 4 nozzles
• 6 mm nozzle diameter
• $0.10/kWh
• 1 minute of blow time per 4-minute cycle
• 3 shifts
• 5 days per week

In that example, the estimated reduced annual air-generating cost for all four nozzles is $3,568.13 per year.

The same example also estimates a reduction of approximately 23.07 tons of CO2 emissions annually. That is a useful illustration of how a relatively simple blow-off application can quietly become a meaningful operating cost when compressed air is allowed to run continuously.

Actual savings will vary based on nozzle size, operating hours, electrical cost, system pressure, compressor efficiency, and application duty cycle. The important part is evaluating the process first. Reducing air consumption only makes sense if the application still performs properly.

The goal is not simply to use less air. The goal is to use only the amount of air necessary to do the work.

4. Oversizing Pneumatic Components

When it comes to pneumatics, bigger is not always better. Oversized cylinders, valves, and tubing can increase air consumption without improving machine performance. For example, cylinder sizing should be based on the actual force required for the application:

Force = Pressure × Piston Area

A larger cylinder requires more air volume every time it cycles. If that additional force is not needed, the system may simply be using more compressed air than necessary.

Proper component sizing should consider factors such as:

• Required force
• Stroke length
• Speed
• Cycle rate
• Available pressure
• Load conditions
• Tubing length
• Valve flow capacity

Parker offers a broad range of pneumatic cylinders and actuators that can be selected around the actual requirements of the application, including 4MA, SR, LP, guided cylinders, and rodless actuator technologies.

Properly sizing the actuator, and then matching the valve, tubing, and flow requirements to it, can help avoid unnecessary compressed-air consumption while still providing the force, speed, and performance the machine requires.

This is also where working through the application with Triad can add value. Rather than simply replacing an existing component with the same size, we can look at the force, flow, pressure, speed, and cycle requirements to determine whether the existing pneumatic system is properly sized.

5. Losing Pressure Through Your Distribution System

Sometimes the issue is not the compressor, it is the path the air takes to reach the machine. Undersized piping, long runs, excessive fittings, contamination, and aging infrastructure can all contribute to pressure loss.

When pressure drops at the point of use, the common response is to increase compressor pressure. While that may address the immediate issue, it can also increase energy consumption across the entire facility. A properly designed compressed-air distribution system helps deliver the required flow and pressure to the machine with minimal pressure drop. Solutions like Parker Transair aluminum compressed-air piping can provide a flexible, corrosion-resistant option for compressed-air distribution while making it easier to modify the system as production needs change.

Start with the Application

Improving compressed-air efficiency does not necessarily mean replacing your entire pneumatic system.

Start by asking a few simple questions:

• What pressure does the application actually require?
• Are leaks contributing to unnecessary air loss?
• Can continuous blow-off be replaced with pulsed airflow?
• Are cylinders, valves, and tubing properly sized?
• Is the distribution system creating unnecessary pressure drop?

The answers can help identify opportunities to reduce compressed-air consumption while maintaining, or even improving, machine performance.

Small Changes Can Make a Big Difference

Compressed air is a valuable utility, and every unnecessary PSI, leak, or oversized component can contribute to higher operating costs. By optimizing pressure, addressing leaks, improving blow-off applications, properly sizing components, and reducing pressure loss, manufacturers can take meaningful steps toward a more efficient pneumatic system.

Triad Technologies works with Parker pneumatic technologies including cylinders, valves, air preparation, fittings, tubing, compressed-air piping, Air Saver products, and other air-management technologies. Whether you are troubleshooting a pressure issue, looking to reduce air consumption, or evaluating a new pneumatic application, our team can help identify the right solution.

Want to find out where your compressed air is going? Contact Triad Technologies and let's take a look at your application.



In recognition of Hose Safety Awareness Month, here are five ways to help improve hose assembly safety.

1. Start With the Application
The STAMPED method is a framework promoted by NAHAD to help identify the requirements of a hose application. STAMPED stands for size, temperature, application, material, pressure, ends, and delivery and helps determine the correct hose and fittings for your application. Before selecting a hose and fittings, consider the operating conditions:

• S – Size: Inside diameter (ID) and length
• T – Temperature: Media temperature
• A – Application: Working conditions and external exposure
• M – Media: Fluid or gas type, and concentration
• P – Pressure: Maximum working pressure
• E - Ends: Fitting style, type, orientation, and attachment
• D -Delivery: Testing, quality, packaging, and shipping needs

The goal is simple: understand how the assembly will be used before determining what components should be used.

Ask the right questions before the assembly reaches the crimper.

2. Proper Components Still Require Proper Assembly
Selecting the right hose and fittings is only part of the equation. The fabrication process must also follow manufacturer specifications and established procedures. Even quality components can become a safety concern when assembled incorrectly.

Key assembly considerations include:

Compatibility
Use hose and fittings designed to work together.
Specifications
Follow manufacturer-recommended crimp dimensions and assembly procedures.
Equipment
Keep fabrication equipment properly maintained and calibrated.
Training
Make sure personnel understand the procedures and requirements involved in building an assembly.

3. Don't Let Installation Create a Problem
A hose can be properly selected and assembled and still fail prematurely because of how it is installed. Poor routing can create unnecessary stress through excessive bending, twisting, stretching, or abrasion.

During installation, watch for:

• Sharp edges and abrasive surfaces
• Excessive bending
• Twisting
• Insufficient room for equipment movement
• Exposure to excessive heat
• Routing that exceeds the hose's recommended bend radius

Think beyond the connection points and consider how the entire hose assembly moves and interacts with the surrounding equipment. A properly installed hose should have the room to work, not fight against its environment.

4. Make Inspection Part of the Routine
Hoses rarely choose a convenient time to fail. Regular inspections can help identify potential issues before they turn into unexpected downtime or a more serious safety concern.

Look for visible warning signs such as:

• Abrasion or worn cover
• Cuts or cracks
• Kinking
• Stretching
• Pinholes or leaks
• Damaged fittings
• Corrosion
• Signs of twisting or excessive stress

But don't stop at the hose itself. Inspect the entire assembly, including fittings, connections, routing, and the surrounding environment.

5. Treat Hose Safety as an Ongoing Process
Hose safety isn't something to consider only when an assembly is fabricated or after a problem occurs. It requires consistent attention throughout the life of the equipment.

A stronger hose safety program may include:

• Ongoing employee training
• Consistent assembly procedures
• Routine inspections
• Documented maintenance practices
• Regular conversations about safety

Hose Safety Awareness Month is a good reminder to evaluate current practices, with the goal to enhance and carry those habits forward throughout the year.

Safer Hose Assemblies Start with the Details
Safe hose assemblies start with understanding the application. It continues through proper component selection and assembly. And it requires attention during installation, inspection, and maintenance. Those details matter because hose assemblies are critical to keeping equipment and operations moving.

This September, take the opportunity to evaluate your hose safety practices, and consider where small improvements could help prevent larger problems down the road.

At Triad Technologies, our team can help you with training and best practices to support your operation. Contact us to talk with a hose and fluid power specialist about your application.
